Features
  • 200W RMS power handling
  • 124 dB max SPL
  • 60 ÷ 20000 Hz frequency range
  • 90° x 70° constant directivity coverage angle, rotatable horn
  • 1 x 8" high power woofer
  • 1 x 1.4" voice coil compression driver
  • High quality plywood cabinet
  • Steel front grille with clothing
  • Installation points available on rear, top and bottom panels
  • 4 pole EUROBLOCK connector (audio input and parallel link output)

COMPACT M 08 is a multipurpose two-way full-range speaker system, suitable for a wide range of applications. Its balanced sound is a big asset in near-field applications for the best intelligibility. The M 08 features high sensitivity, typical of professional audio cabinets thanks to the use of oversized magnets and a HI-FI sound quality, with smooth and wide frequency response, thanks to the wave-guided compression driver. The SPL level of low-distortion audio the M 08 can provide goes far beyond expectations of such a compact solution. The elegant and compact design with accurate finishing makes M 08 suitable for almost any environment, even with architectural constraints. Optional mounting accessories allow using M 08 on wall or ceiling installations.

Part number:

13000594
COMPACT M 08
Black - RAL 9005, EAN 8024530017798

13000722
COMPACT M 08 W
White - RAL 9003, EAN 8024530019341

Black & white

When in need of a particular appearance, matching the colour of interiors, or searching for a stylish, minimalistic sound system for your next DJ set, we can provide you with a full set of white speakers — a tough coating for wooden speakers or a robust white polypropylene composite material for portable systems, pole included, in perfect fashion. Purity and elegance, all available to be included in corporate gigs, weddings, and houses of worship.
Responsive Image

Multipurpose sound

Elegant design aesthetic, multiple formats and RCF signature sound quality that allows to deliver a supreme audio experience in any application, from restaurant and retail shops to clubs, corporate spaces and venues.
Responsive Image

Engage your customers

Compact dimensions and impressive size/weight to SPL output ratio. These are the features that will allow your audience enjoying an immersive musical experience.

Improve the audio atmosphere

Music supports engagement and improves the feeling of hospitality in the environment, especially if the perceived sound quality is higher. This is the aim of RCF Compact M Series - optimal performance in both background music and high powered foreground audio.

Smooth installation

COMPACT M speakers embody the functionality and style you expect of Italian design, always in harmony with the installation environment. Available in a wide range of models for all sizes and power levels, the Compact M series gives you the optimal combination to match with any coverage need. Moreover, the rotatable horn and RCF logo allow both vertical and horizontal speaker installation.

All models are built of high-quality wood, with multiple rigging points for a convenient flying/hanging installation. Thanks to the range of accessories, installation time is minimal. If needed, the EUROBLOCK connection panel can be replaced with a female Neutrik SpeakON one.
Specifications
Acoustical specifications
Frequency Response (-10dB)
60 Hz ÷ 20000 Hz
Max SPL @ 1m
124 dB
Horizontal coverage angle
90°
Vertical coverage angle
70°
Directivity index Q
9
System Sensitivity
95 dB
Power section
Amplification
Full Range
Nominal Impedance
8 ohm
Power Handling
200 W
Peak Power Handling
800 W PEAK
Protections
Dynamic active mosfet
Crossover Frequencies
1800 Hz
Recommended Amplifiers
XPS 16K, XPS 16KD, QPS 10K, QPS 6.0K, IPS 5.0K, IPS 2.5K, IPS 1.5K, DMA 504
Transducers
Compression Driver
1 x 1.0'', 1.4'' v.c
Woofer
1 x 8'', 1.7'' v.c
Input/Output section
Input connectors
Euroblock
Output connectors
Euroblock
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
Plywood
Hardware
6 x M6, 4 x M8, 2 x M10
Grille
Steel with clothing
Color
Black - RAL 9005, White - RAL 9003
Size / Weight
Height
442 mm / 17.4 inches
Width
257 mm / 10.12 inches
Depth
284 mm / 11.18 inches
Weight
10.5 kg / 23.15 lbs
Shipping information
Package Height
477 mm / 18.78 inches
Package Width
322 mm / 12.68 inches
Package Depth
295 mm / 11.61 inches
Package Weight
12.4 kg / 27.34 lbs
