F 6X 6 CHANNEL MIXING CONSOLE WITH MULTI-FX
Search RCF products
Choose search system
MIXING CONSOLES
PORTABLE
F 6X
6 CHANNEL MIXING CONSOLE WITH MULTI-FX
- 2 Mic/Line inputs
- 2 stereo line inputs
- One Aux/FX (post)
- Balanced main output audio path from input to output




























Features
- 2 Mic/Line inputs
- 2 stereo line inputs
- One Aux/FX (post)
- Balanced main output audio path from input to output
- 16 presets PRO DSP internal FX
- Sturdy metal chassis
- External universal power supply
- Designed and engineered in Italy
RCF’s next generation F Series mixers builds on the rich analog legacy found in the professional E Series, featuring high quality sound in five formats from 6 to 24 channels. A powerful tool for the musician and the sound enthusiast, entirely conceived and designed by the RCF R&D team. Housed in a sturdy metal chassis, each mixer features a full balanced audio path from input to output and the unique PRO DSP FX: 16 professional effects such as Reverbs (Halls, Rooms, Plates, Spring), Delays (Mono, Stereo and Multitap), Chorus, Flangers and Echoes. The models F-10XR, F-12XR, F-16XR and F-24XR, include an USB audio interface, for stereo recording on computer-based DAW and 2-channel playback.
Specifications
Electronic specifications
Frequency Response
20 Hz ÷ 20 kHz
THD+N, 20dB gain, 0dBu out
<0,02% A-Weighted
Processing
Dynamic range
> 85dB
Inputs
Channels
6
Mic
2
Gain Range
0 dB ÷ -50 dB
Input Noise Level
-124 dBu A-Weighted
Mic Inputs Impedance
14 kohm
Low Cut
80 Hz
Phantom Power +48V
Yes
Mono Line
2
Gain Selection
20 dB ÷ -30 dB
Line Input Impedance
21 kohm
Stereo Line
2
Gain Selection
20 dB ÷ -30 dB
Stereo Line Input Impedance (kOhm)
15 kohm
Input connectors
XLR, Jack, RCA
Outputs
Main MIX
1
FX Send
1
AUX Output
1
Phones
1
Output connectors
XLR, Jack
Outputs specifications
Main Out Level
28 dBu
Aux Out Level
28 dBu
Phones Out impedance (ohm)
150 ohm
EQ
Input Channels EQ
2 Shelving / 1 Generic
Description
High:+/-15 dB @ 10 kHz Shelving,
Mid:+/-15 dB @ 1,250 kHz, Bell
Low:+/-15 dB @ 100 Hz Shelving.
Mid:+/-15 dB @ 1,250 kHz, Bell
Low:+/-15 dB @ 100 Hz Shelving.
Auxiliary sends
FX POST
1
Internal Effects
Send Effects
1
Other features
Footswitch
Yes
Electrical specifications
Power supply
External
Voltage requirements
100 V - 240 V
Power consumption (MAX)
12 W
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
Metal
Color
Black
Size / Weight
Height
79 mm / 3.11 inches
Width
210 mm / 8.27 inches
Depth
255 mm / 10.04 inches
Weight
1.8 kg / 3.97 lbs
Shipping information
Package Height
122 mm / 4.8 inches
Package Width
378 mm / 14.88 inches
Package Depth
260 mm / 10.24 inches
Package Weight
2.75 kg / 6.06 lbs
