Características
  • 80W RMS power handling
  • 114 dB max SPL
  • 70 ÷ 20000 Hz frequency range
  • 130° constant directivity conical coverage angle
  • 6.5" high power woofer
  • 1" neodymium dome tweeter
  • Self extinguishing plastic body
  • Steel magnetic front grille
  • 4 pole EUROBLOCK connector (audio input and parallel link output)
  • 5 m hanging cable included

PMR 60T is a two-way pendant monitor speaker, suitable for a wide range of applications. Thanks to its elegant and discreet design and refined finishes, it is suitable for all environmental and architectural conditions. Featuring a 6.5’’ woofer and 80 W RMS power, it is also equipped with a transformer for connection to constant voltage lines (70/100 V). The high quality of its transducers (arranged in a coaxial configuration) guarantees faithful and precise musical reproduction throughout the audio spectrum and allows to reach truly remarkable sound pressure levels for such compact products. The connection is simple and safe thanks to the removable four-pole screw terminals. The front grille is fixed by magnets and can therefore be easily removed to access the power rotary switch.


NEW

Part number:

13100098
PMR 60T W
White - RAL 9003, EAN 8024530020606

13100100
PMR 60T B
Black - RAL 9005, EAN 8024530020590

Especificaciones
Especificaciones acusticas
Respuesta en frecuencia (-10 dB)
70 Hz ÷ 20000 Hz
SPL máx. a 1 m
114 dB
Ángulo de cobertura
130°
Sensibilidad del sistema
89 dB
Sección de potencia
Amplification
Full Range
Impedancia nominal
8 ohm
Manejo de potencia
80 W RMS
Manejo de potencia pico
320 W PEAK
Frecuencias de cruce
2500 Hz
Transductores
Tweeter de domo
1 x 1.0'' neo, 1.0'' v.c
Altavoz de bajos
1 x 6.5'', 1.2'' v.c
Sección de entrada/salida
Conectores de entrada
Euroblock
Conectores de salida
Euroblock
Transformador de voltaje constante
70/100 V
Selección de potencia 1
80 W - 125 ohm
Selección de potencia 2
40 W - 250 ohm
Selección de potencia 3
20 W - 500 ohm
Selección de potencia 4
10 W - 1000 ohm
Selección de potencia 5
5 W - 2000 ohm
Cumplimiento estándar
Safety agency
CE compliant
Especificaciones físicas
Material del gabinete/de la caja
ABS
Rejilla
Steel
Color
White - RAL 9003, Black - RAL 9005
Tamaño / Peso
Altura
236 mm / 9.29 inches
Diámetro
300 mm / 11.81 inches
Peso
5.1 kg / 11.24 lbs
Informaciones de envío
Altura de paquete
340 mm / 13.39 inches
Anchura de paquete
362 mm / 14.25 inches
Profundidad de paquete
362 mm / 14.25 inches
Peso de paquete
6.5 kg / 14.33 lbs
Descargas
MANUALES
PDF
1,1 MB
10-03-2023
ESPECIFICACIONES
PDF
402 KB
03-03-2025
PDF
404 KB
03-03-2025
DIBUJOS
DXF
1,4 MB
20-06-2024
PDF
222 KB
20-06-2024
PDF
538 KB
20-06-2024
